Compact Size, Light Weight
- 68mmX53mmX16mm
- 42 grams (battery not included)
Fully Programmable, High Fidelity, Research Grade Performance
- Sample rate up to 1024 samples per second
- No data compression
- 8, 10, 12 or 16 bit resolution
12-Lead / 3-Channel Two Work Modes Switchable By Changing Patient Cable
- 10 wire patient cable (I, II, III, aVR, aVL, aVF, V1~V6)
- 5 wire patient cable ( any 3 leads in V1~V6 )
Lower Power Consumption
- Powered by one AAA size battery
- 24H, 48H, or 7 days of full disclosure
Removable SD Card
- 2 GB records up to 48 hours of true 12-lead ECG at 1024 SPS
128X64 DOT Matrix LCD Display
- Provides on demand ECG view
- Confirms programming instructions
- Visual confirmation of patient hook up
Pacemaker Detection
Two Optional Modes of ECG Data Transfer
- Connected directly with PC through USB connector embedded in the recorder
- Removable SD card.
- 68mmX53mmX16mm
- 42 grams (battery not included)
Fully Programmable, High Fidelity, Research Grade Performance
- Sample rate up to 1024 samples per second
- No data compression
- 8, 10, 12 or 16 bit resolution
12-Lead / 3-Channel Two Work Modes Switchable By Changing Patient Cable
- 10 wire patient cable (I, II, III, aVR, aVL, aVF, V1~V6)
- 5 wire patient cable ( any 3 leads in V1~V6 )
Lower Power Consumption
- Powered by one AAA size battery
- 24H, 48H, or 7 days of full disclosure
Removable SD Card
- 2 GB records up to 48 hours of true 12-lead ECG at 1024 SPS
128X64 DOT Matrix LCD Display
- Provides on demand ECG view
- Confirms programming instructions
- Visual confirmation of patient hook up
Pacemaker Detection
Two Optional Modes of ECG Data Transfer
- Connected directly with PC through USB connector embedded in the recorder
- Removable SD card.
