Cover Tape
Article No: 922AR / 927AR / K98AR / H67AR, etc
Spec: 0.045-0.067mm thick
Memo: Heat activated & PSA cover tape
Material: PET, Glue(Rubber)
Class: Adhesive Products
Origin: China
Usage: It is designed to seal electrical and electronic devices into PS, PC embossed carrier tape to achieve, at the same time, the function of packing, protection and transportation.
Spec: 0.045-0.067mm thick
Memo: Heat activated & PSA cover tape
Material: PET, Glue(Rubber)
Class: Adhesive Products
Origin: China
Usage: It is designed to seal electrical and electronic devices into PS, PC embossed carrier tape to achieve, at the same time, the function of packing, protection and transportation.
Specifications
- 922AR
- Heat activated adhesive cover tapes are engineered to protect and contain surface mount components into PS/PET/PC embossed carrier tapes.
- Description: 922AR
- Appearance: Clear
- Thickness: 0.052-0.058mm
- Tensile Strength: >1.5kg/10mm
- Elongation (%): 30-130%
- Carrier tape: PS\PC
- Length (M): Standard 300M/Roll
- Width (mm): 5.3mm\9.3mm\13.3mm\21.3mm\25.5mm
- 37.5mm\49.5mm\65.5mm
- Different width available
- 927AR
- Heat activated adhesive cover tapes are engineered to protect and contain surface mount components into PS/PET/PC embossed carrier tapes.
- Description: 927AR
- Appearance: Transparent/White, Haze 40-50%
- Thickness: 0.063-0.071mm
- Tensile Strength: 1.5kg/10mm
- Elongation (%): >55%
- Carrier tape: PS\PC
- Length (M): Standard 300M/Roll
- Width (mm): 5.3mm\9.3mm\13.3mm\21.3mm\25.5mm
- 37.5mm\49.5mm\65.5mm
- Different width available
- K98AR
- Heat activated adhesive cover tapes are engineered to protect and contain surface mount components into PS/PET/PC embossed carrier tapes.
- Description: K98AR
- Appearance: Clear
- Thickness: 0.042-0.048mm
- Tensile Strength: 1.5kg/10mm
- Elongation (%): >55%
- Carrier tape: PS\PC
- Length (M): Standard 300M/Roll
- Width (mm): 5.3mm\9.3mm\13.3mm\21.3mm\25.5mm
- 37.5mm\49.5mm\65.5mm
- Different width available
- H67AR
- Pack IC electronic parts, seal with PS 、PC embossed carrier tape.
- 263ER
- Captain PSA Cover Tape is designed to protect and contain surface mount components into embossed carrier tape.
- Description: 263ER
- Appearance: Clear
- Thickness: 0.060-0.064mm
- Tensile Strength: 3.0kg/10mm
- Elongation (%): >80%
- Carrier tape: PS
- Length (M): Standard 200M/Roll
- Width (mm): 9.3mm\13.3mm\21.3mm\25.5mm
- 37.5mm\49.5mm\65.5mm
- Different width available
Certificate
- ISO9001:2000
