Safety functions:
1. Safety beam which installed in the fix-door frame.
2. UPS backup battery ensures the door operates 30 minutes normally if power fails.
3. Install an electro-mechanical lock to ensure the door be locked more safely.
4. Panic breakout: KS1000 could install this function, it could open during emergency time or oversize object. Overlapping position.
Technical Data:
Power supply: 220VAC, 50HZ ,10A
Rated power: 100W
Max drive power (static):150N
UPS backup battery: 30min
Ambient temperature:-30℃～50℃
Max relative humidity:90%
1. Safety beam which installed in the fix-door frame.
2. UPS backup battery ensures the door operates 30 minutes normally if power fails.
3. Install an electro-mechanical lock to ensure the door be locked more safely.
4. Panic breakout: KS1000 could install this function, it could open during emergency time or oversize object. Overlapping position.
Technical Data:
Power supply: 220VAC, 50HZ ,10A
Rated power: 100W
Max drive power (static):150N
UPS backup battery: 30min
Ambient temperature:-30℃～50℃
Max relative humidity:90%
Certificate
- ISO9001
- ISO14001
- UL
- TGA
- RAB
- UKAS and CE
Main Products
Automatic sliding door,revolving door,hermetic door ,door operator
