Outdoor P16 virtual pixel full color led display
The Parameter of P16 Real Pixel Full Color Led Display:
Product Item: BLT-ER16B-2RGBT
Pixel Configuration: 2R1G1B
Package Mode: DIP546
Module Resolution: 16*8 dots
Module Size: 256mm*128mm
Pixel Density: 3906
Brightness: 5000CD
Pixel Pitch: 16MM Material
Scan Mode: Static Scan
Drive Mode: Constant Drive
Brightness Adjust: 100 grades
Cabinet Size: 1204mm*768mm
Cabinet Resolution: 64*48 dots
View Distance: more 16m
Cabinet Color: Black
Max Power : 850w
Average Power: 340W
PC cover: black
Input Signal: S-video,Conpent,RGB,DVI
Work Voltage: DC 5V
Diplay Refresh Rate: More 300HZ,
Display Color: 1024*1024*1024
Gray Grade: 16K
Cabinet Size: 135mm+35mm
Viewing Angle : H/V 110/45
Working Life: 100000 hours
Communication Mode : Cable or Fiber
the feature of P16 real pixel full color led display
1.It has high brightness and adjustable contrast.This model has a good lighting accordance and has no mosaic.
2.Larging view angle,it also has a better viewing effect for text,graphic and video ects,any LED in each pixel
3.can be respectively repaired.
4.Computer VGA screen with real-time synchronization output, and applies to all types of Internet connections with the media to transmit real-time information.
5.Brightness strong, static driving scan mode, larger power-driven,
6.fully guaranteed brightness.In the visual distance of the screen surface direct sunlight, display clearly visible.
7.A gray 4096 super Grey scale control and Y unlined correct function,color display more than 16.7 trillion,close to natural color.
8.With automatic brightness adjustment function, in different light conditions can attain the best effectives.
9.Widely used in stadium,bank,school,restaurant,shopping centre,station,goverment,entertainm]ent centres and so on.
Product Item: BLT-ER16B-2RGBT
Pixel Configuration: 2R1G1B
Package Mode: DIP546
Module Resolution: 16*8 dots
Module Size: 256mm*128mm
Pixel Density: 3906
Brightness: 5000CD
Pixel Pitch: 16MM Material
Scan Mode: Static Scan
Drive Mode: Constant Drive
Brightness Adjust: 100 grades
Cabinet Size: 1204mm*768mm
Cabinet Resolution: 64*48 dots
View Distance: more 16m
Cabinet Color: Black
Max Power : 850w
Average Power: 340W
PC cover: black
Input Signal: S-video,Conpent,RGB,DVI
Work Voltage: DC 5V
Diplay Refresh Rate: More 300HZ,
Display Color: 1024*1024*1024
Gray Grade: 16K
Cabinet Size: 135mm+35mm
Viewing Angle : H/V 110/45
Working Life: 100000 hours
Communication Mode : Cable or Fiber
the feature of P16 real pixel full color led display
1.It has high brightness and adjustable contrast.This model has a good lighting accordance and has no mosaic.
2.Larging view angle,it also has a better viewing effect for text,graphic and video ects,any LED in each pixel
3.can be respectively repaired.
4.Computer VGA screen with real-time synchronization output, and applies to all types of Internet connections with the media to transmit real-time information.
5.Brightness strong, static driving scan mode, larger power-driven,
6.fully guaranteed brightness.In the visual distance of the screen surface direct sunlight, display clearly visible.
7.A gray 4096 super Grey scale control and Y unlined correct function,color display more than 16.7 trillion,close to natural color.
8.With automatic brightness adjustment function, in different light conditions can attain the best effectives.
9.Widely used in stadium,bank,school,restaurant,shopping centre,station,goverment,entertainm]ent centres and so on.
